ICU: Isolation Unit exemplar – Data + Model

Talon has created this brief data set in order to assist clients at this time.
Although every effort has been made to maintain the accuracy of guidance, please note that this example is for information only and all legislative data must be checked by the user prior to  its use in a live project.

** Please note that this data/Revit is purposely minimal for a concentrated ICU treatment in a contagious scenario with infection control flow of use. **

The ADB data set is compatible for ALL versions of ADB, including Data Sheet and layouts supporting AutoCAD users and can be downloaded from the Data categories download.

The Revit model is compatible for Revit 2016 and above and can be downloaded from the Revit categories download.

ADB Revit Library 2016 – update pack, Mar. 2020

This package covers a range of Components/Families (168), for Revit 2016 and above to update the existing standard library, these have been re-drawn in native Revit and populated with COBie parameters.

Please note that the COBie parameters have been intentionally left blank.

To use this supplementary package, unzip the download and overwrite the original ADB families.

This can be found here: [Download]

ADB Revit Library 2016 – update pack, Dec. 2019

This package covers a range of Components/Families (172), for Revit 2016 and above to update the existing standard library, these have been re-drawn in native Revit and populated with COBie parameters.

Please note that the COBie parameters have been intentionally left blank.

To use this supplementary package, unzip the download and overwrite the original ADB families.

This can be found here: [Download]
